26
Wi-Q User’s Manual
Specifications
Note: Varying speaker and amplifier input load impedances may cause the high-pass crossover
frequency to slightly vary. The transmitter range stated above is under ideal conditions. Specifications are
subject to change without notice.
Model Wi-Q10BV/Wi-Q10BVE Wi-Q12BV/Wi-Q12BVE
Woofer 10” (24.5 cm) forward firing
(8.2” piston diameter)
12” (30.5 cm) forward firing
(9.7” piston diameter)
Amplifier Class D Class D
Cabinet Design Extended Excursion
Down-firing port
Extended Excursion
Down-firing port
Frequency Response
Overall
+/-3dB 16 - 240 Hz
28 - 120 Hz 14.6 - 240 Hz
25 - 120 Hz
Voice Coil 2” 2-layer copper 2” 2-layer copper
Cone Reinforced fiber Reinforced fiber
Magnet Structure Weight 5.36 lb 7.40 lb
High-Pass Crossover 80 Hz*, 6 db/octave 80 Hz*, 6 db/octave
Low-Pass Crossover 40 - 135 Hz adjustable
(12 dB/octave, 24 dB ultimate)
40 - 135 Hz adjustable
(12 dB/octave, 24 dB ultimate)
Outputs Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Inputs Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Digital Phase 0, 90, 180, 270 degrees 0, 90, 180, 270 degrees
Auto On/Off Yes Yes
Removable Grill Yes Yes
LED Display Yes Yes
Transmitter Frequency 2.4 GHz 2.4 GHz
Transmitter Range 50’ (15 m) 50’ (15 m)
Accessories Mic, mic stand, remote control,
transmitter, power supply, and
batteries
Mic, mic stand, remote control,
transmitter, power supply, and
batteries
Cabinet (H,W,D)
(includes feet and grille)
17.31” x 15.25” x 17”
(44 x 38.7 x 43.2 cm)
18.44” x 16.375” x 18”
(46.8 x 41.6 x 45.7 cm)
Shipping Weight (approx.) 40 lb (18.2 kg) 45 lb (20.5 kg)
