Subwoofer Controls/Connections/Features
Wi-Q User’s Manual
Subwoofer Controls/Connections/Features
Front Panel
Figure 7: Wi-Q front panel
Following are descriptions of the controls and connections shown in
.
Remote Control Sensor:
IR sensor window receives a signal from the included remote control.
LED:
2.5 digit, seven segment LED readout displays volume, phase and Auto-EQ.
Mic Jack:
Connector for the supplied microphone to use during the Auto-EQ process.
MIC
Mic jack
Remote
control
sensor
LED
