Velodyne WiConnect User Manual
Page 7
wireless Receiver
[ 4 ]
W iConnect System User’s Manual
SET UP
A. OUTPUTS
• L and R: Outputs for connecting to
your subwoofer’s RCA input.
• LFE: Output for connecting to your
subwoofer’s LFE input.
b. ChANNEl SElECTOR: Switch for
choosing the broadcast frequency by
CHANNEL. This CHANNEL selector
switch of the WiConnect System
receiver should be set to the same
CHANNEL as the transmitter.
C. 5V dC Power adapter socket
d. gREEN lEd: Indicates receiver
is active.
