Welcome.

Thisquickstartguideprovidesanintroductiontothe

operationoftheZ3000.TheZ3000isananalog

voltagecontrolledoscillatorwithabuilt-indigital

pulsecounter.Itdisplaysconstantpitchdataata

refreshrateofoneupdatepersecondinthree

differentmodes.Eachmodecanbeaccessedusingthe

ModeSwitch.ThisuniquefeatureputstheZ3000into

aclassofitsownasaVCO,bringingnewcapabilities

ofcomplexsoundsynthesistotheanalogrealm.In

addition,itsimplifiesthesetupofmulti-oscillatorvoices

byallowingpitchintervalstobesetbysight.

ModeSwitch

1.FrequencyMode

2.MusicalNoteMode

3.OctaveMode
