1v/oct cv input and output, 1v/oct, Tipt p – Tiptop Z3000 Smzrt VCO User Manual
Page 11: Cv in, Cv in cv out
1V/Oct CV Input and Output.
MIN
MAX
MIN
MAX
LOW
HIGH
SYNC
HSM
1V/Oct
1V/Oct
Linear FM
INPUT
PWM
FM 1
LOW
HIGH
Hz
Oct
FM 2
INPUT
CV IN
INPUT
CV IN
CV OUT
INPUT
INPUT
+
+
+
+
EXT IN
FREQUENCY/NOTE/OCTAVE
Tipt p
A u d i o
Z 3 0 0 0
Smart VC-Oscillator
FREQUENCY
FINE TUNE
PULSE WIDTH
PWM
FM
MIN
MAX
MIN
MAX
LOW
HIGH
SYNC
HSM
1V/Oct
1V/Oct
Linear FM
INPUT
PWM
FM 1
LOW
HIGH
Hz
Oct
FM 2
INPUT
CV IN
INPUT
CV IN
CV OUT
INPUT
INPUT
+
+
+
+
EXT IN
FREQUENCY/NOTE/OCTAVE
Tipt p
A u d i o
Z 3 0 0 0
Smart VC-Oscillator
FREQUENCY
FINE TUNE
PULSE WIDTH
PWM
FM
1V/Oct
CV IN
1V/Oct
CV IN
CV OUT
It should be known that the CV bus can be enabled
using the HD2 jumper on the main PCB. Further, this
will not override the 1V/Oct CV input on the front
panel.
The 1V/Oct CV IN/OUT jacks let you easily cascade
the CV output coming from a MIDI to CV interface,
quantizer, sequencer or any other CV source.
Connecting a bank of Z3000s to a single CV source
is simple and looks something like this:
MIDI > CV
>
VCO1 CV IN
>
VCO1 CV OUT
>
VCO2 CV IN
>
VCO2 CV OUT
>
VCO 3 CV IN
...etc.
Please note that the maximum number of cascades is
dependent on the output drive of the MIDI to CV or
other CV source used. Typically, it is possible to drive
up to ten modules.
