Tiptop Z3000 Smzrt VCO - Manual (Page 12)

External Input.
Thisisadirectinputintothepulsecounterin
theZ3000.Feedasawtoothwavefromanyother
VCOintothisinputtoadjust,synthesizeandmonitor
thepitchusingallofthefeaturesoftheZ3000'sthree
modeoptions.
TheEXTINisdesignedtoworkwitha10Vpp
sawtoothwave,thoughotherwaveformscanbeused
ifthesawtoothwaveformisnotprovidingastable
reading.Aslongasthesignaldoesnotexceed10Vpp,
asignalfrommostVCOscanbeused.
MIN MAX
MIN MAX
LOW HIGH
SYNC HSM
1V/Oct 1V/Oct
Linear FM
INPUT
PWM FM 1
LOW HIGH
Hz
Oct
FM 2
INPUT
CV IN INPUT
CV IN CV OUT
INPUT INPUT
+
+ +
+
EXT IN
FREQUENCY/NOTE/OCTAVE
Tiptp
A u d i o
Z 3 0 0 0 Z 3 0 0 0
Smart VC-Oscillator FREQUENCY
FINE TUNE
PULSE WIDTH
PWM
FM
Sawtooth
VCO
