Recommend circuit schematic, Serdes ic protocol ic pld / pal, Delta sfp module – Delta Electronics Multi-Rate CWDM SFP Transceiver LCP-155 CWDM User Manual
Page 4: Delta electronics, inc, Depands on serdes ic used
DELTA ELECTRONICS, INC.
4 Jun.,
2007
Rev. 0F
www.deltaww.com
Mask of the eye diagram for the optical transmit signal
Recommend Circuit Schematic
Laser Diode
Photo Diode
1uH
1uH
0.1uF
10uF
0.1uF
0.01uF
0.01uF
0.01uF
0.01uF
0.1uF
10uF
RES1
RES1
100 Ohms*
RES1
RES1
RES1
10k Ohms
100 Ohms
VCC
Protocol Vcc
SerDes IC
Protocol IC
PLD / PAL
Mod_def 2
Mod_def 1
Mod_def 0
3.3V
3.3V
DELTA SFP Module
Preamp &
Tx_Disable
Quantizer
Tx_Fault
TD +
TD -
VeeT
RD +
RD -
Rx_LOS
VeeR
Tx_Disable
Tx_Fault
Rx_LOS
RES1 = 4.7k to 10k Ohms
VccT
VccR
Laser Driver
* Depands on SerDes IC used
EEPROM
