Main Status Screen
NOTE: When remote monitoring via the internet, always hit "Refresh" on the browser
to make sure you are viewing the most up-to-date information.
The Main Status Screen (Figure 11) displays the following "at-a-glance" DS550 chassis status
information (according to SAF-TE Specification Rev. 1.0):
Chassis Status Displays the status of the DS550 chassis.
Temperature Displays the temperature status of the DS550 chassis.
Status
Power Supply Displays the status of each DS550 power supply module.
Status
Blower Status Displays the status of each DS550 blower.
Timestamp Displays calendar date and time.
NOTE: Timestamp is located at the bottom of each SAFTEmon page.
Number of Displays total count of SAFTEmon polls.
Polls
NOTES: Polling interval is factory set at 15 seconds. Interval may be changed
via the SAFTEmon.exe window (Figure 12).
Total count of polls will reset back to "0" once SAFTEmon.exe is
closed.
