Figure b-1: de300 repeater board details – StorCase Technology S20A120 User Manual
Page 26
S20A120 User's Guide - Rev. A01
StorCase Technology, Inc.
Appendix B - Factory-Installed Options
19
Figure B-2: Attaching the Repeater Board
0480b
Receiving Frame
Motherboard
Repeater
Board
Stand-offs
(Replace Motherboard
Mounting Screws)
Remove Mounting
Screws and use to
Fasten Repeater
Board (2 plcs)
Carriers
Installed
0518b
Repeater Board
(Installed)
Carriers
(Installed)
I/O Connector
= Pin 1
Mounting
Hole
Mounting
Hole
S20A130
Repeater Board Detail
DE300
Receiving Frame
Motherboard
Figure B-1: DE300 Repeater Board Details
