S20A120 User's Guide - Rev. A01 StorCase Technology, Inc.
Appendix A - Specifications/Dimensions 17
Figure A-1: DE300 Physical Dimensions
(Dimensions are for reference only)
0.32
(8.1mm) 3.13
(79.2mm)
5.50
(139.7mm)
#6-32 x 4
(Bottom)
Receiving Frame
with Carriers
Installed
Carrier
Only
0522b
#6-32 x 8
(Side)
0.15
(3.8mm)
0.25
(6.3mm)
3.13
(79.2mm)
2.06
(52.3mm)
4.70 (11.9mm)
1.25 (31.8mm)
4.70 (11.9mm)
0.39 (9.9mm)
3.38
(85.9mm)
5.88
(149.2mm)
8.15
(207.0mm)
4.67
(118.5mm)
1.07
(27.2mm)
1.75
(44.5mm)
3.75
(95.3mm)
7.38
(187.4mm)
