Chapter 3: Configuring the 1762sc-OF8 for RSLogix 500 3-7
User’s Manual Pub. 0300246-01 Rev. B
Table 3-4 (Data Format)
Output Range Output Value Condition Raw/Prop EU PID % FS
4..20mA
20.40 mA High Limit 32767 20400 16793 10250
20.00 mA High Range 31176 20000 16383 10000
4.00 mA Low Range -32450 4000 0 0
3.92 mA Low Limit -32768 3920 -82 -50
0..20mA
20.40 mA High Limit 32767 20400 16711 10200
20.00 mA High Range 31482 20000 16383 10000
0.00 mA Low Limit/Range -32768 0 0 0
+/-10V
11.00 V dc High Limit 32767 11000 17202 11000
10.00 V dc High Range 29788 10000 16383 10000
-10.00 V dc Low Range -29788 -10000 0 -10000
-11.00 V dc Low Limit -32768 -11000 -819 -11000
0 to 5V
5.50 V dc High Limit 32767 5500 18021 11000
5.00 V dc High Range 26809 5000 16383 10000
0.00 V dc Low Range -32768 0 0 0
0.00 V dc Low Limit -32768 0 0 0
0 to 10V
11.00 V dc High Limit 32767 11000 18021 11000
10.00 V dc High Range 26809 10000 16383 10000
0.00 V dc Low Range -32768 0 0 0
0.00 V dc Low Limit -32768 0 0 0
1 to 5V
5.50 V dc High Limit 32767 5500 18431 11250
5.00 V dc High Range 26809 5000 16383 10000
1.00 V dc Low Range -20853 1000 0 0
0.00 V dc Low Limit -32768 000 -4096 -2500
3.4.2 Output Data File (Normal Run Mode)
The output data file is used to configure each channel for the OF8 as well as control the
output signal of each channel. Use the addressing scheme shown in Figure 3-2 above.
In normal run mode, output words 0 through 7 control the analog output signal for
channels 0 through 7 respectively. See Table 3-1 above.
Section 3.5
Module Status
Input data for the OF8 consists of status information, channel configuration information
and module configuration status.
3.5.1 Input Data File (Command Mode)
In command mode, the input data file returns module configuration status used during the
configuration process. Refer to section 3.4.1 for more information regarding command
mode. Use the addressing scheme below to locate the 8 input words.
