2-8 MicroLogix™ 1200 IO 8 Ch Output Module
User’s Manual Pub. 0300246-01 Rev. B
Note: All return terminals are electrically tied together, but each output
should use its own associated return terminal for best accuracy.
OUT 0
Shield
OUT 2
OUT 3
OUT 4
OUT 5
OUT 6
OUT 7
RTN 0
RTN 1
RTN 2
RTN 3
RTN 4
RTN 5
RTN 7
NC
NC
RTN 6
+
-
OUT 1
Load
