3-6 MicroLogix™ 1200 IO 8 Ch Output Module
User’s Manual Pub. 0300246-01 Rev. B
Table 3-3 (Data Words 1 through 4)
To Select Channels 1, 3, 5, or 7 Channels 0, 2,4 or 6
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Output
Type
4 to 20 mA 0 0 0 0 0 0
0 to 20 mA 0 0 1 0 0 1
-10 to 10 V 0 1 0 0 1 0
0 to 10 V 0 1 1 0 1 1
1 to 5 V 1 0 0 1 0 0
0 to 5 V 1 0 1 1 0 1
Reserved 1 1 0 1 1 0
Channel Disabled 1 1 1 1 1 1
Data
Format
Scaled for PID 0 0 0 0
Engineering Units 0 1 0 1
Percent Range 1 0 1 0
Raw/Proportional
Data
1 1 1 1
Unused 0 0 0 0 0 0
