Parr Instrument Series 4590 - Manual (Page 25)

4590 Micro Reactors
w w w . p a r r i n s t . c o m 25
Support Stands
4591/4592 Micro Reactor with 1/8 hp Variable Speed Motor
1.49 (DOWN POSITION)
2.05 (UP POSITION)
SW51FT WASHER
MID PLATE
SN5013HX HEX NUT
2218HC
SUPPORT ROD
CONDENSER ROD
TW50FT WASHER
(2) SN5013HX HEX NUT
2202HC COLLAR
(2) TW50FT WASHER
2196HC (OPTIONAL)
(3) 2188HC SPACER
(3) SB2528FS12 SCREW
2198HCAA
1/8 HP MOTOR (W/FILTER)
SN5013HX HEX NUT
BASE PLATE ASSY
A2217HC
(5) SB2528HX08 HEX BOLT
(5) SW25NL WASHER
1/8 HP MOTOR (NO FILTER)
(4) 2188HC ISOLATOR
(5) SB1932SC08 SCREW
1355EES
(4) SW19FT WASHER
2225HC OVERARM PLATE
(2) 2198HC SUPPORT ROD
A1554EES
(4) TA1632PP06 SCREW
(5) TW19NL LOCK WASHER
(4) SA1632RD06 SCREW
2219HC SHIELD MOTOR
2224HC2 BELT GUARD (OPTIONAL)
857HC5 DRIVE PULLEY (SHOWN)
SW51FT WASHER (OPTIONAL)
(4) SB1932BT06 SCREW
2224HC BELT GUARD (STD)
(4) TW19NL LOCK WASHER
(OPTIONAL)
845HC2 RELEASE KNOB
299HC2 BUSHING
328E7 HOLE PLUG
A2223HC DRIVEN SHAFT ASSY
863HC COLLAR
2075HC2 COUPLING
SN5013HX HEX NUT (OPTIONAL)
A2262E TACH PKG
842HC SNAP RING
2202HC ENCASEMENT
847HC4 DRIVE BELT (NOT SHOWN)
1725 RPM (SEE RMP TABLE)
147C4 CONDENSER ROD (OPTIONAL)
732HC SNAP RING
PLATE MICRO
1374HCJV O-RING
839HC BALL BEARING
2231HC BUSHING (OPTIONAL)
A1120HC6 MAG DRIVE ASSY
4591/4592 MICRO REACTOR
2203HC3 SUPPORT
841HC SNAP RING
2208HC SPLIT WASHER
HEATER ASSEMBLY
2206HC VESSEL RETAINER
(NOT SHOWN)
MICRO/MINI (OPTIONAL)
X2170 SHIELD, MAG DRIVE
A3240HC9EB/A3240HC9EE
2207HC PANEL SCREW
SC1932SC08 SET SCREW
A2175HC PULLEY ASSY
858HC2 DRIVEN PULLEY
862HC SUPPORT HUB
14.16
REF
REF
6.58
REF
25.29
17.50 REF
RPM PULLEY BELT
600 RPM 857HC 847HC8
800 RPM 857HC3 847HC8
1000 RPM 857HC4 847HC8
1700 RPM 857HC5 847HC4
