4590 Micro Reactors
w w w . p a r r i n s t . c o m 21
High Pressure Reaction Vessel Parts List
Consult the itemized list for your reactor provided
along with this manual. For purpose of reactor identifi-
cation, the following abbreviation/codes are used:
FH - Fixed Head FG - Flat Gasket
RV - Removable Head SR - Split Ring
* For parts made from alternate materials use the codes
shown below as a suffix to the standard part number.
CM - Alloy 400 CC - Alloy 20Cb3
CT - Alloy 600 CA - Titanium G2 or G4
CG - Alloy B-2 CH - Alloy C-276
CX - Zirconium
Cylinders*
Part No. Description Code
2430HC Cylinder, 25 mL SR FG
2430HC2 Cylinder, 50 mL SR FG
2430HC3 Cylinder, 100 mL SR FG
Heads*
Part No. Description Code
2432HC Head RV FG
2772HC Head FH FG
Split Rings and Accessories
Part No. Description Code
A455HC Split Ring, with six bolts SR RV
232HCFDE Compression Bolt SR RV
A456HC Drop Band SR RV
456HCF2 Drop Band Bolt SR RV
454HC Compression Ring SR RV
A2345HC3 Split Ring w/bolts SR FH
232HCF3DE Compression Bolt SR FH
Gaskets & Seals
Part No. Description Code
48HC Gasket, silver, mag drive
48HCFG Gasket, gold plated, mag drive
429HC2 Flat Gasket, PTFE SR FG
429HC2KL Flat Gasket, Flexible Graphite SR FG
Thermowell*
Part No. Description Code
A2067HC7 Thermowell, 25/50 mL RV
A2067HC6 Thermowell, 100 mL RV
A2067HC5 Thermowell, 25/50mL FH
A2067HC4 Thermowell, 100mL FH
Dip Tube*
Part No. Description Code
1443HC Dip Tube, 25 mL
1443HC2 Dip Tube, 50 mL
1443HC3 Dip Tube, 100 mL
Shaft/Impeller Assembly
Part No. Description Code
A1987HC3 Shaft/Impeller, 25/50 mL RV
A1987HC4 Shaft/Impeller, 100 mL RV
A1987HC5 Shaft/Impeller, 25/50mL FH
A1987HC6 Shaft/Impeller, 100mL FH
Gages
Part No. Description
593HCPD Gage, 3-1/2” 1000 psi/bar
593HCPF Gage, 3-1/2” 2000 psi/bar
593HCPG Gage, 3-1/2” 3000 psi/bar
593HCP40AD Gage, 3-1/2” 4000 psi/bar
593HCP50AD Gage, 3-1/2” 5000 psi/bar
External Fittings
Part No. Description
A451VB Straight Valve 1/4 NPTM
A455VB2 Angle Valve 1/4 NPTF
420HC2 Adapter “A” Socket x 1/4 NPTF
195VBAD Tee, Branch 1/8 NPT MFF
555VBAD Reducing Adapter 1/4F – 1/8M
1401HC Hex Nipple 1/4M – 1/8M
154VB 45° Elbow 1/8NPTM-F
836HC Gage Adapter, ¼” NPT (top), 1/8” (side)
836HC6 Gage Adapter, ¼” NPT (top), (2) ¼” NPT
(side), 1/8” (side)
836HC7 Gage Adapter, ¼” NPT (top), (1) ¼” NPT
(side), 1/8” (side)
A833HC Male Connector for Thermocouple 1/8 T
A138CA* Male Connector for Thermowell ¼ T
A472E2 Thermocouple, SS, 9-1/2” L, 1/8” OD
A472E Thermocouple, SS, 7-1/2” L, 1/8” OD
A472E4 Thermocouple, SS, 5-1/2” L, 1/8” OD
A490E Thermocouple, SS, dual 7-1/2” L, 1/8” OD
A1357E2 Thermocouple, SS, Type J, 9-1/2” L,
1/16”OD
A1357E4 Thermocouple, SS, Type J, 7-1/2” L, 1/16” OD
A888HC2 Safety Rupture Disc Assembly (See 231M)
A1120HC6* Magnetic Drive Assembly
