4590 Micro Reactors
P a r r I n s t r u m e n t C o m p a n y 18
SERIES 4590 VESSEL PARTS LISTS
Standard Vessel Fittings
(3000 psig / 350 °C)
Standard Reaction Vessel Parts List
Consult the itemized list for your reactor provided along
with this manual. For purpose of reactor identification,
the following abbreviation/codes are used:
FH - Fixed Head OR - O-Ring Seal
RV - Removable Head SC - Screw Cap
FG - Flat Gasket SR - Split Ring
* For parts made from alternate materials use the codes
shown below as a suffix to the standard part number.
CM - Alloy 400 CC - Alloy 20Cb3
CT - Alloy 600 CA - Titanium G2 or G4
CG - Alloy B-2 CH - Alloy C-276
CX - Zirconium
Cylinders*
Part No. Description Code
2430HC Cylinder, 25 mL SR FG
2430HC2 Cylinder, 50 mL SR FG
2430HC3 Cylinder, 100 mL SR FG
2900HC Cylinder, 25 mL SR OR
2900HC2 Cylinder, 50 mL SR OR
2900HC3 Cylinder, 100 mL SR OR
1430HC Cylinder, 25 mL SC OR
1430HC2 Cylinder, 50 mL SC OR
1430HC3 Cylinder, 100 mL SC OR
