Installing landing gear – ParkZone PKZ5180 User Manual
Page 8

En
Note: Fairings (PKZ5130) may be removed for flying the
Extra 300 from a rough runway
1. Press together landing gear (PKZ5106) legs and put
landing gear support in slot in bottom of fuselage (painted
bare fuselage, PKZ5167).
2. Release landing gear when support is fully installed in
the fuselage slot.
3. Install left (marked “L”) and right (marked “R”) landing
gear fairings on the landing gear supports and fuselage
using four (4) small screws.
Note: Before flight, make sure wheel nut is tight. If it is not,
use threadlock to secure wheel nut.
Installing Landing Gear
7
