En
Congratulations on your selection of the high performance
aerobatic ParkZone ® Extra 300. The original aircraft was
designed in 1987 by Walter Extra. The Extra 300 is one of the
most recognized full-scale aerobatic aircraft in the world.
Mike McConville designed this park-sized version to give you
a scale aerobatic experience like no other. Rudder control
is pure, so no pitch or roll coupling makes knife edge flight
easier. The Extra 300 is capable of positive and negative G
maneuvers, snap rolls and other precision aerobatics. The
specially designed power system adds vertical performance
too.
Since the Extra 300 can be ready for flight in as little as an
hour, you can spend your time refining your flying skills, not
your building skills.
Note: A full range 4-channel or greater transmitter (SPMR5500,
SPMR6600 or SPMR7700) for the Extra 300 BNF. Transmitter,
receiver, charger and battery required for Extra 300 PNP.
WARNING: Although your ParkZone® Extra 300 comes
almost ready to fly, this aircraft is for experienced RC pilots
only and is not a toy. Misuse of the plane can cause serious
bodily harm and damage to property. Therefore, only an
experienced RC pilot should fly it. Because of the high
performance nature of the Extra, we recommend you only fly
in very large open areas or RC club fields.
Extra 300 PNP/BNF Instruction Manual
Table of Contents
Topic Page
Safety Precautions and Warnings 1
Introduction 2
Low Voltage Cutoff (LVC) 3
Battery Warnings 3
Charging the Flight Battery 4
General Assembly and Maintenance Tips 5
Transmitter and Receiver Binding 6
Installing Landing Gear 7
Installing Wings 8
Installing Horizontal Tail and Pushrods on Control Horns 9
Installing Flight Battery 10
Adjusting Center of Gravity 10
Control Direction Test 11
Reverse Controls 11
Control Surface Travel Measurement 12
Installing Propeller Adapter, Propeller, and Spinner 13
Motor and ESC Removal 14
PNP Installation 15
Range Check 15
Before Each Flying Session 15
Flying Tips 16
Repairs 16
Troubleshooting Guide 17
Replacement Parts and Optional Parts 18
Warranty and Service 19
Contact Information 20 Extra 300 Specifications
Wingspan
Length
Weight (RTF) 40.6 in (1030mm)
36.8 in (935mm)
34.5 oz (980 g)
Extra 300 Features
Bind-N-Fly
Version
Plug-N-Play
Version
Motor
ParkZone 15-size
brushless outrunner
Installed Installed
ESC
E-flite® Pro 30A brushless
with Switch-Mode BEC
Installed Installed
Receiver
Spektrum™ AR500 DSM2
5-channel sport receiver *
Installed
Sold
Separately
Battery
3S 11.1V 2200mAh 25C Li-Po
Included
Sold
Separately
Charger
Variable rate 2- to 3-cell
Li-Po balancing fast charger
Included
Sold
Separately
Transmitter
Full range DSM2
aircraft transmitter *
Sold
Separately
Sold
Separately
* Recommended for Plug-N-Play Version
