8. Specifications
Model
DS10K
C33 II
DS15K
C33 II
DS20K
C33 II
DS30K
C33 II
DS45K
C33 II
DS60K
C33 II
DS80K
C33 II
DS100K
C33 II
DS120K
C33 II
DS160K
C33 II
DS200K
C33 II
Capacity 10KVA 15KVA 20KVA 30KVA 45KVA 60KVA 80KVA 100KVA 120KVA 160KVA 200KVA
Rated Power 8KW 12KW 16KW 24KW 36KW 48KW 64KW 80KW 96KW 128KW 160KW
Power Factor 0.8
Input
Phase 3 Phase 3 Wire or 3 Phase 4 Wire and PE
Voltage Range 10K~120K: 120V/208 or 220V/380V ±20%; 160K~200K: 220V/380V ±20%
Frequency Range 50Hz / 60Hz ±5Hz Auto Sensing
Rectification 6 Pulse (Standard) / 12 Pulse (Optional)
Rectifier Efficiency >97%
Inverter Efficiency >88%
Output
Phase 3 Phase 3 Wire or 3 Phase 4 Wire and PE
Voltage 120V/208V or 220V/380V
Stabilization ±1%
Transient 90% Resumption after 4 Cycles
Overload Capacity
>101% ~ 124% Transferred to bypass after 30 minutes
>125% ~ 150%  Transferred to bypass after 10 minutes
>150%  Transferred to bypass after 1 minute
Inverter Topology IGBT Design, DSP Control, 20KHz PWM Sine Wave
Frequency 50Hz / 60Hz
Frequency Stabilization ±0.1%
Phase Lock Range ±5Hz
Phase Unlock Range >±5Hz
Phase Relock Range ±3Hz
Waveform Sine Wave
Crest Factor 3:1
THD <3% for Linear Load
Static Transfer Switch
Transfer
UPS transfers from bypass mode to inverter mode
as the voltage and the frequency of the inverter and the utility are synchronized.
Cold Start Transfer 2 Level Voltage Transfer
Transfer Time
Bypass mode to inverter mode 0ms
Inverter mode to bypass mode 0ms
Efficiency >99%
Charger
Voltage DC220V / DC410V DC410V DC435V
Current 1.5~10A 3~20A 5~30A 15~50A
Time 100% discharged and then recharged to 90% in 8 hours (depending on battery specifications)
* Specifications are subject to change without notice.
