4-1-2 Unpacking
(1) Cut off packing ropes and take out packing coverings as Fig. 4-1-2a, 4-1-2b and 4-1-2c illustrate.
(2) Unwrap PE coating.
(3) Unscrew screws of L fixers screwed on the pallet as Fig. 4-1-2d and 4-1-2e illustrate.
(4) Follow the arrow marks to unload the UPS as Fig. 4-1-2 illustrates.
Fig. 4-1-2a Fig. 4-1-2b Fig. 4-1-2c
Fig. 4-1-2d Fig. 4-1-2e
Fig. 4-1-2f
Unscrew
Unscrew
