HydroSport
1
Screw a Butterfly Top into the OptiMount located on
the upper wall adjacent to the rowing seat or area. Be
sure to remove the plastic insert from the OptiMount
center.
Use the OptiMounts identified by a
1
in the 1-2-3
picture.
2
Simply screw each rower into an OptiMount on the wall on each side of
the rowing seat as previously shown. Be sure to remove the plastic insert
from the center of the OptiMount.
Use the OptiMounts identified by a
2
in the 1-2-3 picture.
A good guide for measuring the correct installation of the rowers is to ensure that you
first screw the rower into the OptiMount until it is almost snug, then back off ½ turn.
Next continue to back it off slightly until the rings on the rower are horizontal.
