Beta 1-8 LSC&
Beta 2-8 LSC&
10 Technical data
Version 04/2013, Rev. 1.1 of 16/12/2013 • sb
89
Translation of the original operating manual
Connection requirements
(without vacuum pump and
accessories)
Beta 1-8 LSC
plus
Beta 2-8 LSC
plus
Electrical connection: 1 x 230 V / 50 Hz
(other supply data on request) 1 x 230 V / 50 Hz
(other supply data on request)
Protection class: I I
IP protection category according to
DIN 60529:
11 11
Nominal power: 0.92 kVA 1.1 kVA
Nominal current: 4.0 A 5.0 A
Mains fuse: 10 A 12 A
Pressure control valve connection: 230 V, 50/60 Hz, 20 VA max. 230 V, 50/60 Hz, 20 VA max.
Vacuum pump connection: 230 V, 50/60 Hz, 2 A max. 230 V, 50/60 Hz, 2 A max.
Filling quantity: Beta 1-8 LSC
plus
Beta 2-8 LSC
plus
Refrigerant See name plate See name plate
Physical data (without vacuum
pump and accessories): Beta 1-8 LSC
plus
Beta 2-8 LSC
plus
Dimensions
- height:
- width:
- depth:
415 mm
780 mm
540 mm
(incl. vacuum flange connection)
415 mm
780 mm
540 mm
(incl. vacuum flange connection)
Weight: approx. 63 kg approx. 78 kg
Noise level according to DIN
45635:
54 dB(A)
54 dB(A)
EMC according to EN 55011: Class B Class B
Heat emission: 0.6 kW min.
1.1 kW max. 1.1 kW min
1.6 kW max.
Equipment connections: Beta 1-8 LSC
plus
Beta 2-8 LSC
plus
Vacuum connection: Small flange connection DN25KF
(ISO 28403, DIN 2861) Small flange connection DN25KF
(ISO 28403, DIN 2861)
Media drain valve: Hose nozzle DN10
(outside diameter 12 mm) Hose nozzle DN10
(outside diameter 12 mm)
Aeration valve: Hose nozzle DN4
(outside diameter 8 mm max.)
Hose nozzle DN4
(outside diameter 8 mm max.)
Vacuum sensor: SUB D-9
VSP 62 SUB D-9
VSP 62
Data interface (LAN): RJ 45 RJ 45
Special equipment: water
cooling system Beta 1-8 LSC
plus
Beta 2-8 LSC
plus
