10 Technical data
Manufacturer: Martin Christ
Gefriertrocknungsanlagen GmbH
An der Unteren Söse 50
37520 Osterode
Germany
Type: Beta 1-8 LSC
plus
Beta 2-8 LSC
plus
Part number: 102124 102125
Performance data: Beta 1-8 LSC
plus
Beta 2-8 LSC
plus
Ice condenser
- capacity:
- performance:
- temperature:
- chamber volume:
8 kg max
6 kg / 24 h max
approx. –55°C
approx. 11 l
8 kg max
6 kg / 24 h max
approx. –85°C
approx. 11 l
Temperature of the ice condenser
during hot-gas defrosting:
approx. +60°C
approx. +60°C
Possible shelf temperatures
( process A): freezing and drying
inside the ice condenser chamber
approx. –25°C to +60°C
approx. –50°C to +60°C
Possible shelf temperatures
( process B): drying outside the
ice condenser chamber
Room temperature to +60°C
Room temperature to +60°C
Max. shelf surface area
( process A): drying inside the
ice condenser chamber
1 shelf, 200 mm
A
total
=0.031 m 2
1 shelf, 200 mm
A
total
=0.031 m 2
Max. shelf surface area
( process B):
drying outside the ice condenser
chamber
drying in injection vials with sealing
under vacuum or nitrogen
atmosphere outside the ice
condenser chamber
drying in round bottom flasks
10 shelves, Ø 200 mm each
A
total
=0.31m 2
or
5 shelves, 375 mm each
A
total
=0.55 m 2
6 shelves, 200 mm each
A
total
=0.186 m 2
12 pieces or 24 pieces
10 shelves, Ø 200 mm each
A
toal
=0.31m 2
or
5 shelves, 375 mm each
A
total
=0.55 m 2
6 shelves, 200 mm each
A
total
=0.186 m 2
12 pieces or 24 pieces
