4.4 Packaging
The freeze-dryer is packaged in a wooden crate.
• After opening the packaging, take out the accessories.
• Remove the packaging material.
• Remove the side walls of the crate.
• Lift the freeze-dryer upwards and out of the crate/cardboard box. When
lifting the unit, always reach under the freeze-dryer from the side.
CAUTION
The freeze-dryer Beta 1-8 LSC
plus
weighs approx. 63 kg!
The freeze-dryer Beta 2-8 LSC
plus
weighs approx. 78 kg!
CAUTION
The centre of gravity of the freeze-dryer is off-centre!
• Retain the packaging for any possible future transport of the freeze-
dryer.
Pos: 86 / 010 Unive rsalm odul e/ L ee rzeile @ 0\ mod _120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 87 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Beta 1- 8_2 -8 LSCpl us/0 40 L age run g un d T ra nspo rt/0 40- 005 0 Tra nspo rtsich eru nge n Beta @ 16 \mo d_1 359 106 5676 69_ 68. docx @ 80 773 @ 2 @ 1
4.5 Transport safety devices
Prior to start-up, the vacuum sensor must be installed (see chapter 5.5 -
"Vacuum sensor").
NOTE
Prior to any transport, the transport safety devices must be deinstalled.
