Menu tree
NOTE: When selecting among several options for a control, the active selection is highlighted in red.
Press Menu
IN
→
TYPE → Input type selection as appropriate for current input
DVI -D Digital-Video-Interface (HDMI compatible)
4:4:4 Digital-Video-Interface (HDMI 4:4:4 compatible)
4:2:2 Digital-Video-Interface (HDMI 4:2:2 compatible)
DVI -A Digital-Video-Interface (HDMI compatible)
SDYPBPR Component using the SDTV color-space
HDYPBPR Component using the HDTV color-space
RGBS RGB with separate composite sync
RGsB RGB with composite sync on green
SDI Serial Digital Interface
OUTSEL If output in INDEP mode, select one of 8 output configurations
CONFIG →
COLR →
BLCK Use display black for selected input
CONT Use display contrast for selected input
COLR →
COLR Color saturation (Use “blue” color bar pattern)
HUE Hue (Use “blue” color bar pattern)
COLRED Red Color saturation offset (Use “red” color bar pattern)
HUERED Red Color Hue offset (Use “red” color bar pattern)
COLGRN Green Color saturation offset (Use “green” color bar pattern)
HUEGRN Green Hue offset (Use “green” color bar pattern)
CUE Chroma-Upsample-Error mitigation filter
CTMP Grayscale and gamma calibration (Service mode only)
ADJ →
SIZE →
TOPL Position top-left of input
BTMR Scale to position bottom-right corner of input
NLS Select 4:3 input as normal or Non-Linear-Stretch
SCALE Disable scaling if input resolution matches out resolution
MASK Adjustable Mask to cover the four sides of the video.
YC-DLY Y/C delay independently for C
B
and C
R
SHARP Select image sharpness. Not available for most VisionDVI inputs
LEVEL DVI-D levels or Analog black-pedestal (PC or Video)
NAME Name input memory by following on-screen instructions
CNTRL →
DEINT → Deinterlacing control
MODE Select deinterlacing mode
FIELD Flip input fields (i.e. swap odd and even fields)
GENLOCK Select genlock mode
DVI → For DVI inputs, select modes
HDCP Select if DVI input reports HDCP capability
EDID Select EDID as Lumagen default, monitor values, or off
HOTPLG Select if “hotplug” remains asserted when input not selected
COPY →
ALL Copy current input memory to selected input memories
COLOR Copy the current input memory’s color parameters (only)
