13
3.0 Dimensions
SM6 Sensor
Panel Cutout
Dimensions
( Front view )
74mm
(2.91 ″)
10mm
(0.39 ″)
10mm
(0.39 ″)
17mm
74mm
(2.91 ″)
12mm
(0.47 ″)
12mm
(0.47 ″)
20mm
(0.79 ″)
25mm
(0.98 ″)
25mm
(0.98 ″)
27mm
(1.06 ″)
12mm Dia.
(0.47 ″)
for
SM1 cable
30mm Dia
(1.18 ″)
Sensor Hole for
Vent Tube
SM6 Sensor
Dimensions
( Rear view )
2 x Holes for self tapping fixing
screw.
[ 4mm (0.157 ″)Fixing Hole
provided on SM6 sensor ]
