Smt power inductor, Silm4018 type, Features

background image

RoHS compliant.
Low profile(1.8mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
Self-leads ,suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.

Features

0.00

0.01

0.10

1.00

10.00

CURRENT (A)

1.00

10.00

100.00

IN

D

U

C

T

A

N

C

E

(u

H

)

4R7

6R8

100

150

1R5

220

2R2

330

3R3

SMT Power Inductor

SILM4018 Type

53

25 : 100KHz, 0.1V

O

C

1. Tolerance of inductance : 30%.
2. Irated is the DC current which cause the inductance drop 35% typical of its nominal inductance without current and the surface
of the part increase less than

o

45 C.

o

o

3. Operating temperature : -20 C to 105 C (including self-temperature rise).

Electrical Characteristics :

1

PART NO.

L

DCR

(m ) MAX

Irated

(Adc)

2

(uH)

2.2

B

D

E

A

F

1.7

C

5.4

Mechanical Dimension :

UNIT:mm/inch
A = 4.0 / 0.157 Max.
B = 4.0 / 0.157 Max.
C = 1.8 / 0.071 Max.
D = 4.8 / 0.189 Max.
E = 2.9 / 0.114
F = 1.0 / 0.039

RECOMMENDED PAD PATTERNS

DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com

SILM4018 - 1R5

1.5

52

1.55

SILM4018 - 2R2

2.2

72

1.20

SILM4018 - 3R3

3.3

85

1.10

SILM4018 - 4R7

4.7

105

0.90

SILM4018 - 6R8

6.8

170

0.73

SILM4018 - 100

10.0

210

0.55

SILM4018 - 150

15.0

295

0.45

SILM4018 - 220

22.0

430

0.40

SILM4018 - 330

33.0

675

0.32
