PARTS
BURNER ASSEMBLY MODELS VC36N, VVC36N, VC36P, VVC36P,
CGCDV36NR AND CGCDV36PR
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 37 of this manual.
KEY
NO. PART NO.
DESCRIPTION
QTY.
1
**
Burner Pan Assembly
1
2
**
Base Grate
1
3
**
Firebox Base Bottom
1
4
26808
Valve Bracket
1
5
11107
Screw, #10-32 x 1/4 Zinc
4
6
**
Firebox Bottom
1
7
11102
Screw, #8-32 x 3/8 Zinc
2
8
121877-01 Aluminum Tubing Assembly
1
9
111288-02 Flex Gas Line
1
10
108084-02 Pilot Assembly NG
1
108084-03 Pilot Assembly LP
1
108084-05 Pilot Assembly (-HA Models)
1
11
14389
Natural Gas Valve
1
14390
Propane/LP Gas Valve
1
117370-01 Natural Gas High Altitude Valve
1
12
11165
Screw, #10 x 5/8 Zinc
23
13
111913-01 Burner Base Gasket
1
14
14500
Brass Fitting
2
15
116345-01 Pilot Bracket
1
16
26827
Switch Bracket
1
17
11226
Flat Washer 7/8" ID x 2" OD
2
18
11214
Bulkhead Fitting with Washer
2
19
14296
Elbow 3/8"
1
20 24873
Burner Orifice #36 NG
1
23097
Burner Orifice #52 LP
1
21
14492
Piezo Ignitor
1
22
14511
Piezo Bracket
1
PARTS AVAILABLE - NOT SHOWN
108085-03 Pilot Assembly (-HA Models - NG)
1
**Not a field replaceable part.
