www.desatech.com 116200-01L 29
OPERATION
Continued
ON/OFF SERIES MODEL HRC100
Hold the control button on the hand-held remote
until burner turns on. Hold the control button
again until burner turns off (see Figure 47).
TO LOCK press both buttons on hand-held
remote control until light stops flashing. Hand-
held remote control is now locked. If the fire
is on it will be turned off automatically. In the
locked state, the light will not light up when
any button is pressed.
TO UNLOCK press both buttons together on
hand-held remote control until the light stops flash-
ing. The hand-held remote is now unlocked.
Figure 47 - On/Off Hand-Held Remote
Control Unit HRC100
Control
Button
Indicator
Light
THERMOSTAT SERIES MODEL
HRC200
The hand-held remote can be operated using
either the manual mode (MANU) or thermo-
static mode (AUTO) (see Figure 48). To select
Fahrenheit/Centigrade mode display, carefully
press the ˚C/˚F mode button with the end of a
paper clip or similar blunt object.
Manual Mode
1. Press the POWER and LOCK buttons
together to turn on the hand-held remote
control.
2. Press the MANU button to turn on the
fireplace.
3. Press the POWER and LOCK buttons
together to turn off the fireplace.
Auto (Thermostatic) Mode
1. Press the POWER and LOCK buttons
together to turn on the hand-held remote
control.
2. Press AUTO button to select this mode.
3. Set the desired room temperature by
pressing the TEMP + or - buttons.
4. Press the POWER and LOCK buttons
together to turn off the fireplace
Note: Do not leave the hand-held remote in the
AUTO mode close to the fireplace. The radiant
heat from the fireplace will turn off the fireplace.
Ideally, place the hand-held remote in the center
of the room facing towards the fireplace.
Note: Do not hold the hand-held remote for
a long time. Body temperature will affect its
operation in the AUTO mode.
Figure 48 - Thermostat Hand-Held
Remote Control Unit HRC200
LOCK
MANU AUTO
ºC/ºF
TEMP
POWER
ROOM
TEMP SET
TEMP
AUTO
Turns
Hand-Held
Remote On
or Off and
Allows You
to Choose
the Manual
Setting
Selects
AUTO
Mode
°C/°F Mode Button
Locks
System to
Prevent
Accidental
Ignition
Turns
Burners
On or Off
Increases or
Decreases
Room
Temperature in
AUTO Mode
Digital Display Shows
Temperature and Settings
Safety Features
When away from home for an extended period
of time or as a child safety feature to prevent
accidental ignition of the fireplace, the receiver
ON/OFF/REMOTE switch should be in the
OFF position.
Auto Shutoff Feature
1. If the average room temperature reaches
a range of 82° F (28° C) to 92° F (33° C),
the hand-held remote control will perform
a safety override and shut the fireplace
off. This feature is not available in the
MANU mode.
2. The receiver continuously receives signals
from the hand-held remote to control the
room temperature. If the hand-held remote
is misplaced, obstructed or for any reason
cannot transmit to the receiver, the receiver
will shut off the fireplace. This will occur in 8
or more minutes depending upon location of
remote transmitter and strength of batteries.
Key Pad Lock Feature
This feature allows the user to lock/unlock the
keypad on the hand-held remote in the MANU
or AUTO mode to prevent inadvertent op-
eration (i.e. children operating the hand-held
remote control, etc.). The keypad is locked in
either on or off. Press the POWER and LOCK
buttons together to turn the unit on or off.
