www.desatech.com 116200-01L 39
PARTS
MODELS VC36N, VVC36N, VC36P, VVC36P, CGCDV36NR AND CGCDV36PR
SERIES
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 37 of this manual.
REFRACTORY BRICK PANELS
VC36NB(-HA)
VC36PB
CGCDV36NR
CGCDV36PR
VVC36NB(-HA)
VVC36PB
V36NH
V36PH
VVC36NH
VVC36PH DESCRIPTION qTY
110989-02 110989-01 111215-02 111215-01 Left Refractory Brick Panel 1
110991-02 110991-01 111217-02 111217-01 Rear Refractory Brick Panel 1
110990-02 110990-01 111216-02 111216-01 Right Refractory Brick Panel 1
KEY
NO. PART NO.
DESCRIPTION QTY.
1 ** Firebox Assembly 1
2 ** Face Weldment 1
3 108010-01 Door Assembly 1
108010-02 Door Assembly (V Models Only) 1
4 108011-01 Top Louver Assembly 1
5 108011-02 Bottom Louver Assembly 1
6 ** Fireplace Top 1
7 ** Fireplace Top Insulation 1
8 ** Fireplace Surround 1
9 109082-01 Heat Shield 1
10 116215-01 Log Set with Grate Assembly 1
11 116338-01 Right Burner Log 1
12 116339-01 Left Burner Log 1
13 See Below Left Refractory Brick Panel 1
14 See Below Rear Refractory Brick Panel 1
15 See Below Right Refractory Brick Panel 1
16 108719-01 Screen Rod 1
17 12105 Screen 2
18 11418 Push-On Nut 2
19 14123 Strain Relief 1
20 21171 Gas Knock-Out Cover 2
21 24353 Handy Box Assembly 1
22 24460 Gas Conduit Assembly 1
23 116210-01 Burner Assembly NG (see page 40) 1
116210-02 Burner Assembly LP (see page 40) 1
116211-05 Burner Assembly for High Altitude Models (See page 40) 1
24 116374-01 Plenum 1
25 118372-01 Top Pilot Shield 1
26 120945-01 Bottom Pilot Shield 1
PARTS AVAILABLE - NOT SHOWN
25487 Lava Rock/Bag Assy 1
27253 Notice Label 1
55240 Vent Label 1
116388-01 Grate Finial 2
** Not a field replaceable part.
