www.desatech.com 116200-01L 26
4. Remount new frame at hinge with 5 new
screws before closing door. This will en-
sure seating of gasket.
5. Close glass door frame. Lock latches by
placing bar under tab on door and pushing
down and back on latch (see Figure 42,
page 25).
6. Replace screen/rod assembly by revers-
ing step 1.
7. Replace louvers by reversing procedure
under Removing Louver Panels, page 25.
Cleaning Glass Door
See Cleaning and Maintenance on page 31.
INSTALLING LAVA ROCK AND
GLOWING EMBERS
It is very important to keep logs exactly as
installed. Do not modify logs. Only use log set
designed for this fireplace. Logs under log/grate
assembly are attached to burner. Do not attempt
to move these logs as this will damage logs.
WARNING: Logs are unitized
and attached to the grate. Do not
handle log/grate assembly by
logs. Always pick up by grate.
Open louvers, remove screen, unlock door
latches and open glass door. See Removing
Glass Door, steps 1 and 2, page 25.
1. Pull ember material apart into pieces no
larger than a dime. Place these pieces
loosely and sparingly directly onto exposed
front section of burner (see Figure 43). This
will create the glowing ember appearance
as flame touches ember material. Do not
block air slots by using too much ember
material in one area. Do not block pilot
ports with embers. It is not necessary to
use all of the ember material provided.
2. Pour lava rock onto plenum but not onto
flat burner. It is not necessary to use all
of the lava rock provided.
NOTICE: Do not put lava rock on
burner or under burner. Placing
lava rock on burner will cause
performance problems.
3. Close glass door, lock door latches, replace
screen and close louvers (see Removing
Glass Door, steps 5 through 7).
FIREPLACE INSTALLATION
Continued
WARNING: The glass door
must be securely in place before
running this fireplace. Do not run
this fireplace if glass is missing
or broken.
Figure 43 - Placing Ember Material on
Burner
Embers
Plenum
INSTALLING BRICK LINER MODELS
BL36DA(SA) AND BL36DHA(SA)
WARNING: If fireplace has
been running, turn off unit. Let
cool before installing brick liner.
You may purchase brick liner from your local
retailer or see Accessories, page 42.
CAUTION: Always handle
brick panels with two hands.
Do not force brick panels into
place. Excessive force will break
brick panels.
1. Remove top and bottom louvers to allow
access to door latches.
2. Unlock door latches and open glass door.
See Removing Glass Door, steps 1 and 2,
page 25.
3. Carefully remove lava rock and ember
material. Remove log/grate assembly
by unscrewing grate from plenum. The
two logs under the grate are attached to
burner. DO NOT attempt to remove.
4. Remove screws that attach plenum to
burner to remove plenum.
5. Remove three screws from deflector
shield on inside top of firebox. Set shield
and screws aside.
