Specifications 29
General Specifications
Design and specifications are subject to change without notice.
Dimensions and weight are approximate. Problem Solution
Cannot tune to one or
more channels. • The program you want to watch
may be blocked through the
parental controls. For more
information, see “Setting parental
controls” on page 25 or “Turning
the parental lock on or off” on
page 24.
• The channel may have been
deleted from the channel list. You
can tune to the channel by
pressing the number buttons or
you can add the channel back to
the channel list. For more
information, see “Deleting
channels” on page 15.
Password is lost. • On the Lock menu, enter 1397 for
the password, then set a new
password. For more information,
see “Setting the parental
password” on page 24.
Cannot access some
items. • If a setting or option is grayed out,
it is not available in the current
input mode.
TV cabinet creaks. • When you are using your TV, the
temperature inside the cabinet
increases. This causes the cabinet
to expand or contract, which
produces the creaking noise. This
is not a malfunction.
Buttons do not work. • Unplug the power cord for a few
seconds, then plug it back in and
turn on your TV.
TV type LCD
TV panel 37-inch TFT LCD
TV system NTSC-M, ATSC
Channels VHF: 2 - 13
UHF: 14 - 69
CATV: 1 - 125
CADTV: 1-135
DTV: 2 - 69
Audio multiplex BTSC system
Audio output 7 W × 2
Power requirement AC 120 V, 60 Hz
Power consumption 220 W
Dimensions 36.6 Ч 26.6 Ч 11.8 inches
(93 Ч 67.6 Ч 30 cm)
Weight 42.9 lb. (19.5 kg)
Input terminals Composite video/left and right audio × 1
S-Video
Component video/left and right audio × 2
HDMI × 2
VGA/audio
Antenna
Output terminals Composite video/left and right audio
Headphone jack
S/PDIF (optical)
Control terminals RS-232
