28

ENGLISH

INFORMATION

TECHNICAL DATA

This device complies with the EU directive
89/336 EEC.

HARDWARE FEATURES

Processor:

7

Samsung S3C2410 266 MHz application processor

GPS chipset:

7

SiRF Star II LP chipset with Xtrac v2 firmware

Memory:

7

64 MB SDRAM for system memory (for user
applications and map storage)

7

64 MB Flash ROM onboard flash memory (for operating
system and embedded applications)

Power:

7

High density rechargeable 2200 mAh Lithium Ion
battery
– Up to 6 straight hours of operation (backlight in 10%

and GPS locked)

– 6 hours charging time from empty to full capacity via

car charger or AC adapter

7

Recharging options
– Indoors using the AC adapter
– On-the-road using either the car charger

7

Power status LED indicator

Display:

7

3.5-inch screen for a wider viewing angle

7

320 x 240 QVGA screen with 16.7M colors for a full-
color display

7

200-nit LCD provides higher brightness, high contrast
and low power consuming display

7

TMR (Transmissive with Micro Reflective) technology
allows the screen to display well-reproduced images
even under bright outdoors lighting

7

Hardware backlight control via the power button

Audio:

7

2W built-in speaker

7

3.5 mm stereo earphone jack on the device

Connectivity:

7

USB port

7

SD/MMC slot

Hardware command interface:

7

Volume control hot keys

7

Image magnification level hot keys

7

Main menu hot key

7

Navigation hot key

7

Multi-directional joystick

GPS SPECIFICATIONS

Chipset:

7

SiRF Star II LP chipset with Xtrac v2 firmware

Receiver:

7

12 parallel channel, WAAS enabled

Antenna:

7

Integrated patch antenna for optimum satellite pick up
at every angle

7

Optional connection for external antenna when the
vehicle’s windshield has a heat reflective shield

Navigation software (DG features):

7

Destinator Address Manager

7

Favorite destination hot list

7

Destination history

7

Navigation mode support for driving

7

Trip planner

Map database:

7

NAVTEQ digital map database

7

Following navigation systems are available with pre-
installed map material on the SD card:
– Nav100 with Benelux, France and UK/Ireland
– Nav100 with Germany and Alps
– Nav100 with France, Iberia and EU roads
– Nav100 with Alps, Italy and Greece
– Nav100 with Finland, Scandinavia and EU roads

TTFF (Time To Fix First, typical):

7

Reacquisition: 1 sec.

7

Hot start: 8 sec.

7

Warm start 35 sec.

7

Cold start: 55 sec.

Accuracy of position fix (horizontal position):

7

10 m for 90%

Velocity:

7

0.1 m/s

Protocol:

7

NMEA-0183 v3.0 supporting the following commands:
– GGA
– GGL
– GSA
– GSV
– RMC
– VTG
