Model SC-DV-2
4
1.2 Features
• Converts Digital DVI from any PC (or digital output from a DVD
player) to analog VGA or component output.
• Ideal for use with high-resolution displays such as LCD, plasma, or
DLP projectors.
• The resolution of any PC or HDTV video signal can be scaled up or
scaled down to any other PC or HDTV resolution. It can also change the
frame rate of the output.
• 50 MB Video memory for real-time frame rate conversion.
• Signal format conversion between RGBHV and YPbPr.
• Input: PC(VGA/SVGA/XGA/SXGA) + HDTV(480i 576i 480p 567p
720p 1080i), @ 60 to 85 Hz
• Output: PC
(VGA/SVGA/XGA/SXGA) + HDTV (480p/576p/720p/1080i)
• Automatically detects input mode and timing parameters
• Easy- to- use push buttons and OSD menu control.
2. Installation
2.1 Input connection
The SC-DV-2 can accept both PC and HDTV input in digital DVI format.
Use the DVI-to-DVI cable to connect the DVI output of a PC or HDTV
device to the DVI input connector of the SC-DV-2.
The SC-DV-2 can automatically detect the mode and resolution of the DVI
input.
2.2 Output connection
The SC-DV-2 can output a variety of PC and HDTV resolutions in analog
RGBHV (or YPbPr) formats.
When one of the PC resolutions is selected as the output, use a 15-pin D-
Sub VGA cable to connect the PC/HDTV output of the SC-DV-2 to the
VGA input of a display monitor.
