DVI - to - VGA Video Scaler
9
5. Specifications
General
Input Format: Digital RGBHV, YPbPr, YCbCr
Input Connector: 29-pin DVI-I
Output Signal:
RGB: 0.7Vp-p, 75 ohm, HV: 3 to 5 Vp-p TTL
Y: 1 Vp-p 75 ohm; PbPr: 0.7 Vp-p 75 ohm
Output Connector: HD-15 Female VGA
Power:
5V DC at 2 A max (Universal power supply included)
Input Resolutions
PC Resolutions HDTV Resolutions
VGA 640 X 480@60/72/75/85Hz 1080i 1920 X1080@60Hz
VGA 70 720 X 400@70Hz 720p 1280X 720@60Hz
VESA 85 640 X 400@85Hz 576p 720X 576@50Hz
SVGA 800 X 600@60/72/75/85Hz 576i 720X 576@50Hz
XGA 1024 X 768@60/70/75/85Hz 480p 720 X 480@60Hz
Mac 1152 X 864@ 70/75Hz 480i 720 X 480@60Hz
WXGA 1280 X 768@60Hz
1280A 1280 X 960@60Hz
SXGA 1280 X 1024@60/75Hz
Output Resolutions
PC Resolutions HDTV Resolutions
VGA 640 X 480@60/72/75/85Hz 1080i-RGB 1920 X1080@60Hz
VGA 70 720 X 400@70Hz 720p-RGB 1280X 720@60Hz
VESA 85 640 X 400@85Hz 576p-RGB 720X 576@60Hz
SVGA 800 X 600@60/72/75/85Hz 480p-RGB 720 X 480@60Hz
XGA 1024 X 768@60/70/75/85Hz 1080i-YPbPr 1920 X1080@60Hz
Mac 1152 X 864@ 70/75Hz 720p-YPbPr 1280 X 720@60Hz
WXGA 1280 X 768@60Hz 576p-YPbPr 720 X 576@60Hz
1280A 1280 X 960@60Hz 480p-YPbPr 720 X 480@60Hz
SXGA 1280 X 1024@60/75Hz
