VGA + Power Over UTP

6

Wallplate Power Connection

The wall plate units have a 2 pin screw

terminal for power connection on the back of

the unit. You need to connect 6 vDC (could

be 6 to 9vDC) to these terminals.

In your package there is either of the 2 power

supplies pictured. There is also a 2.5 mm

Jack included in the package so that you

don’t have to cut the connector at the end of

the power supply. If you decide not to cut off

the power supply connector, then solder a

pair of wires to the enclosed jack and connect

those to the power terminals.

Using the supplied 2.5mm Jack also gives you the ability to place the power

supply outside the wall. You can use a separate single gang plate and install the

supplied jack on it and wire it to the terminals on the back of the wall units.

You can use 20 awg or heavier wire to extend the DC output cord of the power

supply if you need to locate the power supply farther from the device. It is

recommended to keep the distance of the supply from the unit to within 30 feet.

Note: Please do not connect the power supply to the AC source until you have

securely connected the output cords to the Wall Plate Mini-Cat unit.

Electrical Safety Note

Since the DC supply to the unit is only 6 to 9 vDC with minimal current

requirements, the product qualifies as a Class 2 low-voltage device, and

you are not required to run the DC cables in a conduit. However if you will

be installing the power supply in the wall or ceiling, since it has to plug in

to AC, you need an electrical junction box for it, and the AC line that

brings high-voltage to the junction-box should follow the electrical code

for your specific installation
