VGA + Power Over UTP
4
2.0
Features
•
Transmit video and power on one cable
•
Senders with multiple outputs for splitting to multiple displays
•
Handles resolutions up to 1920x1440
•
Drives standard CAT5 cables to 500 feet
•
Adjustable cable length compensation at each receiver
•
Only one power supply required for sender and all receivers
•
Rugged, Reliable, Compact size
3.0
Setup and Operation
A. Place the sender near the video source and connect it to your source using
the cable provided.
•
For PC’s VGA output use a HD15 male-to-male cable (generally a short
cable may be included with your package)
•
For RGB or YPbPr sources, use a HD15 to 3 RCA cable (Hall Research
Model # CHD15-3RCA-length 03 = 3ft, 06 = 6 ft).
•
B. Use an Unshielded Twisted Pair (UTP) or a Shielded Twisted pair (STP)
cable such as Cat5, 5e, or 6 wired per standard 568B to connect the sender to
the receiver(s). See Section 3.1 for important cable selection considerations.
