VGA + Power Over UTP
The characteristics of the Sender units are summarized below:
Feature
Local
Loop Out
RJ45
Outputs
Power Over
UTP
Wall
Mount
UV1-S
No
1
Yes
No
UV1-S-DP
No
1
Yes
Yes
UV1-S-WP
No
1
Yes
Yes
UV1-SL
Yes
1
Yes
No
UV1-SL-DP
Yes
1
Yes
Yes
UV2-S
Yes
2
Yes
No
UV4-S
Yes
4
Yes
No
UV8-S
Yes
8
Yes
No
Table 1 - Sender Characteristics
Note: For Cat-5 runs of over 330 feet, the receivers may need their own
additional supplies sold separately (HRT model # 511-GS569).
1.1
Note for –CV models:
The Mini-Cat ® series senders can be built to extend Composite Video and
Stereo Audio up to 2000 feet, and are sold with HD15 to 3 RCA A/V cables.
These models are labeled with –CV (e.g.: UV2-S-CV) and are not compatible
with VGA signals. The Model UV1-SL is also capable of extending Composite
Video & Stereo Audio by setting a dip switch (see section 3.2).
