9

VGA + Power Over UTP

4.0

Specifications

Video Formats

RGB, and YPbPr, plus CV and line level stereo

audio for UV1-SL

Resolutions

Up to 1920 x 1440 non-interlaced at 60Hz

Bandwidth

DC to 250 MHz

Maximum Distance

Up to 500 ft. (152 meters) for VGA and

Component Video models, or 2000 ft (609m) for

Composite Video and Audio models

Connectors

HD15 female for video input and output, RJ45 for

CAT5 outputs

Compliance

CE; FCC Part 15 Subpart B Class A, IC Class

Power

From utility-power (mains) outlet, through

included external Universal power supply. Output

Voltage: 9 DC Center-Positive,

Do not substitute any other external power

supply without contacting the factory first.

Dimensions

UV1-R

0.8" H x 1.7" W x 4.5" L

UV1-S

0.8" H x 1.7" W x 4.5" L

UV1-R-DP Single-gang Decora
UV1-R-WP 4.4” H x 2.8” W x 0.98” D
UV1-S-DP Single-gang Decora
UV1-S-WP 4.4” H x 2.8” W x 0.98” D
UV1-SL

1.1" H X 2.75" WxX 3.1" L

UV1-SL-DP Single-gang Decora
UV2-S

1.22" H x 4.86"W x 2.60"D

UV4-S

1.22" H x 8.20" W x 3.00" D

UV8-S*

1.32" H x 7.58" W x 3.88" D

*UV8-S has 2 L-shaped mounting ears that protrude 0.88” beyond the main box on each

side. 4 mounting holes are present on a rectangular pattern of 8.62" x 2.63")
