Hall Research 714.641.6607 Page 6
A A u u t t o o S S o o u u r r c c e e M M o o d d e e
The wall plate has the ability to detect the presence of video on its inputs
and automatically switch to the input with active video.
You can enter the Auto Source mode either from the wall plate or by using
the USB GUI. From the GUI you can also lock the Auto Source mode (so it
will stay in that mode permanently). To enable Auto Source mode first
make sure the wall plate is on. Press and hold the Source button for 3
seconds. The red LED above the Source button will turn on (and blink
slowly). This indicates that the wall plate will automatically select inputs.
In this mode, pressing the Source button will not change inputs.
If the wall plate is turned off and back on, it will recall this mode.
If the Auto Source mode is not locked by the GUI, you can exit this mode
from the wall plate. Make sure the wall plate is on, then press and hold the
Source button for 3 seconds. The red LED above the Source button will
turn off.
Notice The user can prioritize inputs, in case more than one is active.
As shipped from factory, HDMI 1 has the highest priority, then HDMI 2,
and last the VGA input. So if the only active input is VGA and you plug in
a source to HDMI 2 or HDMI 1, the wall plate will select the HDMI input.
Priorities can be changed through the USB port using the free manager
software GUI (Graphical User Interface).
If you do not want inputs to usurp each other, you can assign the same
priority level to them in the GUI. That way, once an input is detected, the
wall plate will stay on it until the video is disconnected.
Component Video cannot be auto-detected. So if you are connecting
YPbPr Component to the VGA input, you must select it manually.
