GPSW-1000/2000/3000
___________________________________________________________
4
2.2 GPSW-2000 W Inverter
SPECIFICATIONS GPSW-2000 (12V) GPSW-2000 (24V)
Continuous Output Power 2000 W
Surge Rating 4000 W
Output Waveform Pure Sine Wave <3% THD
Output Voltage ± 5% 115 VAC RMS
Input Voltage 10.5 – 15 VDC 21.0-30.0
Efficiency 85-92%
No Load Current Draw / Powersave 2.8A / 0.6A 1.5A / 0.3A
Protection
Overload, Short Circuit, Reverse Polarity (Fuse),
Over/Under Input Voltage, Over Temperature
Low Battery Alarm ± 2% 10.7 V 21.4 V
Low Battery Shut-Down ± 2% 10.3 V 20.6 V
Operating Temperature Range 0 - 40ºC / 32ºF - 104ºF
Storage Temperature Range -30ºC - 70ºC / -22ºF - 158ºF
Cooling Thermostatically Controlled Fan
AC Receptacle Dual GFCI
Remote Port Option Yes
Dimensions (L x W x H) in mm 422 x 208 x 166
Dimensions (L x W x H) in inches 16.6 x 8.2 x 6.5
Weight 9.5 kg / 21 lbs
Warranty 2 Years
Inverter Install Kits GP-DC-KIT4 GP-DC-KIT3
UPC 8-39085-00068-7 8-39085-00069-4
