Page 11
11
4 Electrical Installation
14212
Hydraulic Plan 2
SOLAR
COLLECTOR
BOILER
FLOW
FLOW
HOT
WATER
CONNECTION
SOLAR
COLLECTOR
SOLAR
COLLECTOR
CIRCUIT PUMP
AUTO AIR
SEPARATOR
MOTORISED
2 PORT VALVE
MOTORISED
2 PORT VALVE
TUNDISH
THERMOSTAT
MIXER
FLUROCYL
DRAIN VALVE
RETURN
RETURN
EXPANSION
RELIEF
VALVE
(6.0 BAR)
PRESSURE
LIMITING VALVE
(3.5 BAR)
WITH LINE
STRAINER
COLD
WATER
SUPPLY
PUMP
EXPANSION
VESSEL
TEMPERATURE
AND PRESSURE
RELIEF VALVE
(95 °C, 7 BAR)
LEGIONNELLA
LOOP (optional)
N
S
E
W
Collector arrays setup for East / West orientation
