INTRODUCTION
1 Instructions guidance
1.1 Product documentation
The instructions are an integral part of the appliance and must be
handed to the user on completion of the installation in order to
comply with the current regulation.
• Carefully read the manual, to understand all the information
to enable safe installation, use and servicing. No liability can
be accepted in the event of damage for not complying with the
guidance in this instruction manual.
These instructions consist of, Installation, Servicing, Fault Finding
and Replacement of Parts. The instructions are an integral part of
the appliance and must be handed to the user on completion of
the installation.
1.2 Associated documents
- 1 Instructions for user
- Instructions for other system components
1.3 Explanation of symbols
a
DANGER: Risk of injuries.
e
DANGER: Risk of electric shock.
b
ATTENTION: Risk of damage to the appliance or to its
surroundings.
i
IMPORTANT: Important information.
1.4 Guarantee registration
Thank you for installing a new Glow-worm appliance in your home.
Glow-worm appliances are manufactured to the very
highest standard so we are pleased to off er our customers a
Comprehensive Guarantee.
This product is guaranteed for 24 months from the date of
installation or 30 months from the date of manufacture,
whichever is the shorter, for parts and labour.
The second year of guarantee, from the beginning of the 13th
month onwards after installation or manufacture, is conditional
upon the heat pump having been serviced by a competent
person approved at the time by the Health and Safety Executive,
in accordance with the manufacturer’s recommendations. We
strongly recommend regular servicing of your appliance, but
where the condition is not met, any chargeable spare parts or
components issued within the applicable guarantee period still
benefi t from a 12 month warranty from the date of issue by the
manufacturer.
We recommend you complete and return as soon as possible your
guarantee registration card (delivered with the hydraulic module).
If your guarantee registration card is missing you can obtain a
copy or record your registration by telephoning the Glow-worm
Customer Service number 01773 828100.
2 Appliance description
2.1 Safety devices
- This appliance is designed for use in heating with an external
temperature of between -20°C and 30°C. Outside this range,
the heat pump stops.
- A set of security devices based on measuring the temperature
within the circuits and the current in the compressor protects
it against excess pressure in the refrigerating fl uid.
- A fl ow detector protects the appliance as a whole.
- To prevent stagnation of the refrigerant fl uid when the
compressor is stopped, a safety device is activated when the
outside temperature lowers. The compressor is then heated by
a low electrical current through the motor windings,
- A temperature sensor on exit from the compressor limits the
functioning of the heat pump when the temperature measured
by this sensor is greater than 100°C. From 117°C, the heat
pump stops.
- A temperature sensor on the fi nned heat exchanger and a
tachometer on the fan checks that the fan is working.
- A water fl ow sensor ensures the security of the water
circulation. If the fl ow is too low (< 420 l/h), the appliance
stops and re-starts when the fl ow comes within the normal
functioning range (>500l/h).
