mount which product by FeiYu Tech,it can meet the requirements of most of the conditions,
and in addition you need to try to reduce the vibration of the motors and oars
.
Installtion position:Each modules install to a suitable position is conducive to further
enhance the performance of Hovering mode. DoS&41AP module installation position
should be as far as possible to close to the center of the aircraft, the aim is to reduce the
disturbance to the internal IMU position sensoring when the aircraft tilt or rotate. In
addition also you have to consider a very important factor, that is as far as possible to
reduce the interference to the DoS&41AP internal magnetic sensor which caused by
installation position. There will be caused interference to magnetic sensor,such as
surroundings have strong current, motor rotation, battery, etc. We need to do is to give full
consideration of these two factors, compromise to select a suitable position for install it.
GPS module should be placed as far as possible to the center position,that can reduce the
interference to GPS data when it level rotating. Also you can put the GPS module to a high
place use a stent, the practice shows that can effectively reduce the interference to GPS
signals which caused by other devices, and improve the positioning performance of GPS
module.
We recommed using suspending damping installation, especially use DoS&41AP
vibration absorbing mount which product by FeiYu Tech.(You can find purchase method
from FeiYu official website:
)
Installation process as follows:(You need a allen driver)
1.Use screws to install the four support columns on the baseboard;
