The GPS Module must be connected to the DoS&41AP with at least 5 GPS satellites
detected.In this Mode, pitch, roll, yaw and altitude control method is the same as Hovering
Mode. Pitch, roll sticks released will automatically fly the aircraft bac k to the take-off
point,
Maximum return to home point speed: 5.5m/s.
 Camera Gimbal Stabilization
DoS&41AP multi-rotor firmware,when is used to control the aircraft under 6 axis,
can simultaneously control two axis Camera Gimbal Stabilization
 DoS&41AP can connect with the Hornet-OSD and the Data Radio
DoS&41AP has one UART interface for connecting the FY-data radio and the OSD
module. It can realize the following function by combing them.
First Person View (FPV): Can be connected to the Hornet - OSD, the flight data
overlay to video output,and through the vodeo transmission system to send back, let you
enjoy the fun of FPV. And it will be easier to operate FPV with the functions of automatic
balance, Hovering and Auto Return To Launch.
Real time telemetry-real time monitor: Real time telemetry-real time monitor the
flying state, using the Data Radio to lengthen the remote control distance.
For more information, please refer to the FY-OSD and FY Data Radio manual.
Attention:
FY-41AP has integrated OSD video overlay system, so you do not need to
connect external video overlay module.
1. DoS&41AP standard configuration：
Standard configuration
●DoS&41AP control module *1;
●RC receiver connecting wires * 1;
●USB cable *1;
●Velcro double sided tape * 2;
Optional accessory
●DoS&41AP vibration absorbing mount *1;
●GPS module *1;
●Hornet OSD module(
DoS optional accessory ) ;
●Data Radio;
●Remote Adaptor;
2. Technical Specification:
DoS module
Input voltage : 4.0 ~ 6.0 Volt;
Current : 50mA (5V);
Size : 47 x 30 x 11 mm;
Weight (excluding wires) : 25g;
Temperature range : -25 ° C ~ +70 ° C;
Control frequency :400HZ ;
Maximum rate of rotation
: ≤ 2000 °/s.
