Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyudz.cn E-mail: [email protected] Page 12
Attention:RC mode Setting of your controller has to be fixed wing model, and every
channels’ maximum and minimum value to be the default value (100%), all the sticks trim
to 0
, also cancel all the curve set .
9. Motor start-up instruction:
Start Motor：When using multi-rotor firmware, pushing throttle stick before takeoff will
not start motors. You have to execute Combination Stick Commands (CSC) in stabilized
mode
(Can not in Hovering mode or Auto Return To Launch Mode(RTH)) to start motors.
Meet the following conditions:
 Put Throttle stick to the lowest position
 Put Aileron stick to any endpoint position
 Put Elevator stick to any endpoint position
 Put Rudder stick to any endpoint position
Combination Stick Commands only need to execute for the first time power on and
take off , the purpose is to prevent motor from wrong start, after execute Combination
Stick Commands the motor will run at Idle Speed, now the throttle stick is at minimum
position, at this time if you want to stop the motor running, you need to push throttle stick
to idle speed above, and then put it to the minimum position, idle speed value default is
1170 us, the throttle stick below 20%. Take off again you do’t need to the execute
Combination Stick Commands when you (If you do not have power off and power on).
10. Gyroscope Reset:
The Red LED flashes continuously even when the DoS&41AP remains stationary,that
means you need to do the Gyro reset.The Gyro reset must be done before the Combination
Stick Commands,after execute Combination Stick Commands you can not do the Gyro
reset.
Initialization / Reset Process:
1.Power on DOS&41AP and keep stationary.
2.Switch to stabilized mode.
3.On SW1,switch stabilized mode to hovering mode 6 times, time interval has to be less
than 3 seconds as follows:
stabilized mode→hovering mode →stabilized mode →hovering mode →stabilized
mode→hovering mode →stabilized mode →hovering mode →stabilized mode →hovering
mode →stabilized mode →hovering mode.
4,DoS&41AP indicator will turn white
about one second.
5,After white LED turns off, the re-setting / initialization is completed.
11. Calibrate the Compass
Ferromagnetic substances placed on aircraft or around its working environment will
affect the reading of earth magnetic for digital compass, it also reduces the accuracy of the
aircraft control, or even reads incorrect heading. Calibration will eliminate such influences,
and ensure DoS&41AP system performs well in a non-ideal magnetic environment.
