FeiYu Tech FY-41AP User Manual
Page 10
Guilin Feiyu Electronic Technology Co., Ltd
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyudz.cn E-mail: [email protected] Page 10
2.Stick the solid foam pads (dampers) to the cover board four interior Angle position;
3.Stick the cover board to the DoS&41AP upper surface (LOGO character surface); you
can appropriately increase DOS&41AP module weight to improve the damping effect, you
can stick copper sheet or other sheet metal which cannot be magnetized on the bottom of
the DOS&41AP (Otherwise the magnetized sheet metal will disturb the internal magnetic
field sensors).
4.Use screws to fix the cover board to the four support columns;
5.Stick the circular ring foam pads (dampers) to the four rounded corners on the baseboard
vibration absorbing mount.Then fix it as far as possible to the position of barycentre on
aircraft
