Optical power meter (opm) operation mode, Other useful features, Introducing the ppm-350c pon power meter – EXFO PPM-350C PON Power Meter User Manual
Page 8
Introducing the PPM-350C PON Power Meter
2
Optical Power Meter (OPM) Operation Mode
3 calibrated wavelengths and up to 40 predefined wavelengths (from 1260 nm
to 1650 nm), each with their own correction factor.
Possible to take reference values for each of the available wavelengths.
Selectable unit (dB or dBm).
Other Useful Features
Automatically shuts down after 10 minutes of idle time (auto-off).
You can manage data directly on the unit (storing, recalling, deleting).
The Handheld Data Transfer (provided on your CD) enables you to create new
threshold sets and correction factors, define your list of favorite wavelengths, as
well as set storage and job options for better data management, or modify
values retrieved from your unit.
You can transfer the data (measurements) directly from your unit to a computer
using the USB port. This will allow you to view them with FastReporter, the
EXFO’s post-processing software.
Liquid crystal
display (LCD)
DC connector
Keypad
Stand
Shoulder
strap eyelet
Status LEDs
