EPM-500/ELS-500/EOT-500 22
To delete a cable name:
1. From normal operating mode, hold down
a
few seconds. The Recall indicator is displayed
with the last cable name, then the last saved value
and its fiber ID.
2. When fiber ID is displayed, hold down a few
seconds to return to the cable name list, then,
select the cable you want to delete by using
and to move forward or backward.
3. Hold down a few seconds. The unit displays “dEL”, then displays another
cable name.
4. Press to return to normal mode.
To delete all saved data from the unit:
1. From normal operating mode, hold down
a
few seconds.The Recall indicator is displayed with
the last cable name, then the last saved value and
its fiber ID.
2. When fiber ID is displayed, hold down both
and a few seconds. The unit displays “dEL”
and “ALL”, then automatically returns to normal
mode.
