Models A & B: LCD Panel Open 1 - 7
Quick Start Guide
1
Models A & B: LCD Panel Open
Figure 1 - 2
LCD Panel Open
1. Built-in PC Camera
2. PC Camera LED
3. Built-In Microphone
4. LCD
5. Power Button
6. LED Indicators
(Caps, Num &
Scroll Lock)
7. Keyboard
8. Touchpad &
Buttons
8
Touchpad Buttons
(valid operation area)
3
5
1
7
4
6
Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines
indicated on the right.
2

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission de-
vices aboard aircraft is
usually prohibited. Make
sure the 3G/WLAN/Blue-
tooth module(s) are OFF if
you are using the comput-
er aboard aircraft.
Use Fn + F11 Airplane
Mode key combination to
toggle Airplane Mode On/
Off, and check the LED in-
dicator for the power status
(see
Table 1 - 4, on
page 1 - 12 / Table 1 - 2,
on page 1 - 9 ). 8
